The Phoenix Project

Westboro (Ottawa, Ontario)

Summer 2017

The Story of The Phoenix Project

Project Type Custom House
Client Private
Neighbourhood Westboro
Concept Contemporary Sustainable Design (Passive House Concepts & Net Zero Ready) Including Nanny Suite (Age in Place)
Contractor RND Construction - A Leader in Energy Efficient and Environmentally Friendly Homes http://rndconstruction.ca/
  The Phoenix Project is a single-family home based on Passive House concepts in order to achieve a Net Zero Ready home.  Named The Phoenix Project as a fire rendered the existing house condemned.  It is the perfect setting to demonstrate how houses should be built with careful consideration for the user, neighbourhood and environment. Site Situated mid-block in a quaint Ottawa neighbourhood (Westboro) this project location is prime for sustainable living.  With its close proximity to main street shops, parkway bike paths, Ottawa's transit way, it offers an opportunity to live without a vehicle or with little reliance on one.  It is perfect for the client's family with a walking lifestyle.  The property has an east-west orientation and faces east, crucial for both Passive Solar and Passive Ventilation concepts.  The site zoning easily supports the growth and flexibility required to change as the family grows.  However, ARCA-VERDE intends to do so with as small a footprint (house size) as possible. Continue reading »

The Story of The Phoenix Project

Project Type Custom House
Client Private
Neighbourhood Westboro
Concept Contemporary Sustainable Design (Passive House Concepts & Net Zero Ready) Including Nanny Suite (Age in Place)
Contractor

RND Construction – A Leader in Energy Efficient and Environmentally Friendly Homes

http://rndconstruction.ca/



The Phoenix Project is a single-family home based on Passive House concepts in order to achieve a Net Zero Ready home.  Named The Phoenix Project as a fire rendered the existing house condemned.  It is the perfect setting to demonstrate how houses should be built with careful consideration for the user, neighbourhood and environment.

Site

Situated mid-block in a quaint Ottawa neighbourhood (Westboro) this project location is prime for sustainable living.  With its close proximity to main street shops, parkway bike paths, Ottawa’s transit way, it offers an opportunity to live without a vehicle or with little reliance on one.  It is perfect for the client’s family with a walking lifestyle.  The property has an east-west orientation and faces east, crucial for both Passive Solar and Passive Ventilation concepts.  The site zoning easily supports the growth and flexibility required to change as the family grows.  However, ARCA-VERDE intends to do so with as small a footprint (house size) as possible.

Appearance

The client challenged ARCA-VERDE to arrange the house to permit natural light in every regularly occupied room or area.  In addition to natural light, the client also requested maximal natural ventilation.  The east to west orientation and house form serves to allow light penetration and foster natural airflow throughout.  The form, as a result, is an expression that is elegant and unimposing.

We believe the result is a new architectural language celebrating the existing urban fabric, our environmental responsibility and the family’s needs.  Three opportunities to produce something of merit.



Interior

The intention of the expansive interior views within the Phoenix Project are achieved by an open concept plan, allowing maximum penetration of natural light and offering few obstacles for natural ventilation.  However, the open concept plan offers areas of repose and isolation.  In either a spa-inspired washroom, private master bedroom or the studio space at the front of the house on the second floor, each is intended to be a place to seek when independence or recharge is needed.

Technology

It is an ARCA-VERDE desire that all technology within a house have little to no presence.  This can be difficult with sustainable ideals but in The Phoenix Project it is achieved by allowing the architecture to be the first response.  Rather than relying on technology or equipment to heat, cool and ventilate the building shape, interior configuration and placement of windows serve as the primary methods.  Low operable windows permit air infiltration and high operable windows permit exfiltration.  Careful placement of interior partitions and operable transoms eliminate obstacles.  The east-west orientation with large windows facing south allows the winter sun to heat the interior eliminating almost all need for supplemental mechanical heat.  This also allows adequate natural light in all rooms.  The only interior room without a window uses a solar tube mounted to the roof to deliver natural light.

Age in Place and Functional Description

In order to allow for family growth and change The Phoenix House is prepared to receive simple upgrades to be truly barrier free.    For example, the house has planned for an elevator with space for a shaft and thickening of the basement slab.  The basement space is ready to receive a granny suite or secondary dwelling unit.  A ramp, that has been planned, would be built to the front door.

While entertaining the dining room is large enough to host 8-10 people with comfort.  The kitchen is modest in size but has a large amount of storage and designed to be the hub of the house.  A feature of the kitchen is a washroom, pantry and recycle center hidden behind kitchen cabinets.  The living room is a formal area with conversational seating or a nice place to read the paper while morning light bathes the room.

The functional layout intends to be void of formal circulation.  Overlapping functions foster a creative and friendly environment without bolstering the house size. Three fireplaces are located throughout to offer ambiance and on demand heat source.

ARCA-VERDE has considered every detail in the Phoenix Project. The placement of functions and arrangement of space creates an economy of space.  Designing with the environment in mind creates a home with a low impact on the earth, a bright interior, and reconnects occupant with exterior environment.   In the most basic of explanations, ARCA-VERDE turned each of the Phoenix Project’s challenges into an opportunity to develop something of merit.

Material and Design Feature

  • Local exterior and interior materials
  • Low VOC paints and adhesives.
  • Forest Stewardship Certified wood
  • Triple pane high performance windows
  • Super insulated roof, walls and floor
  • Provisions for future photo-voltaic panels on mono-sloped roof sections
  • Cistern water collection off mono-sloped roofs
  • Reuse of salvaged materials from the existing burnt structure (brick, glass and armour stone).
  • Xeriscaping landscaping that required no additional irrigation beyond natural rainfall.
